Cybex Free Weight Owner’s Manual
Page 10
*
Language Key
1-German 2-French 3-Spanish 4-English 6-Japanese 7-Swedish 8-Russian
1
1
08229
P/PIN,DETENT
2
2
11040-440
KNOB
3
1
11040-790
DECAL, MADE IN U.S.A.
4
5
11090-374
END
CAP
5
1
11090-376
RING, HANDLE GRIP
6
4
16010-311
FOOT
PAD
7
1
16020-322
PUSH
PUCK
8
2
16060-311
PLASTIC
GUIDE
9
2
16060-315
PLASTIC
GUIDE
10
1
16170-002
CABLE
S/A
11
1
16170-200
BENCH
FRAME
12
1
16170-201
BENCH
13
1
16170-202
LEG
SUPPORT
14
1
16170-203
INSIDE ADJUSTING TUBE
15
1
16170-204
OUTSIDE ADJUSTING TUBE
16
1
16170-323
P/PIN,DETENT
17
3
16170-326
PIVOT
SHAFT
18
1
16170-328
GRIP
19
1
16170-332
SPACER,
SPRING
20
1
16170-335
PULLEY, CABLE, 2.00 OD
21
2
3900-433
DECAL, CYBEX 1.00 HOR (SEE COMPUTER)
22
1
4400-354
PULLEY ASSEMBLY - 3.50
23
1
4715-346
COMPRESSION SPRING .72 x 1.50 LG
24
1
51198
WARRANTY BOOKLET (NOT SHOWN)
25
2
BS070201
COM SPRING .56 x .66 1.50 LG
26
4
FB030232
BEARING, RADIAL 17 mm EXTENDED RACE
27
2
FB130207
BRG FLG 17mm X 19mm X 25mm
28
4
FC030006
TOLERANCE RING 1.575 ID
29
4
HC620431
BHSCS .250-20 X 2.00
30
1
HC622808
SHCS .250-20 X .250
31
9
HF449063
INSERT 3/4 X 1/4-20
32
1
HM532812
SHCS .138-6-32 x .50 GR 8
33
4
HM583208
SREW 10-32 X .25 LG
34
1
HN704400
NUT, HEX JAM .375-16
35
1
HN704901
LOCKNUT, .375-16 NYLON
36
4
HP286810
SPRING PIN .188 X .37 LG
37
6
HS347600
WASHER, SAE .375
38
1
JC620422
BHSCS .250-20 x 1.50
39
6
JC700412
BHSCS .375-16 X .50
40
2
JC700420
BHSCS .375-16 X 1.25
41
1
JC700424
BHSCS .375-16 X 1.75
42
2
JS347400
LOCKWASHER, INT TOOTH .375
43
7
PP130003
INSERT, DOMED PLASTIC
44
1
PP130007
INSERT, DOMED PLASTIC
45
1
PP460011
KNOB, OVAL .375-16 x 1.25 MALE
46A
4
4800-135
LEG PAD W/WEAR COVER
46B
4
4800-138
LEG PAD WEAR COVER
47A
1
4800-420
SEAT PAD W/WEAR COVER
47B
1
4800-423
WEAR
COVER
48
1
5220-364-X
DECAL,
WARNING
49
2
8500-025-X
DECAL,
CAUTION
ITEM
QTY PART NO. DESCRIPTION
