5
CONTROL PANEL AND FEATURES
DRYER CYCLE KNOB
Use your Dryer Cycle knob to select available cycles on your
dryer. Turn the knob to select a cycle for your laundry load.
See the “Cycle Guide” chart for detailed descriptions of
cycles.
TIMED DRY
Will run the dryer for the specified time on the control. On
models with a selectable temperature knob, you may choose
a setting based on the fabrics in your load. Drying time and
temperature will depend on your dryer model.
SENSOR CYCLES/DRYNESS LEVEL
Senses moisture in the load and air temperature and shuts
off when the load reaches the selected dryness level. This
setting gives the best drying in the shortest time. Drying time
will vary based on fabric type, load size, and dryness setting.
1 TEMPERATURE
Select a drying temperature based on the fabrics in your
load. If you are unsure of the temperature to select for a
load, select the lower setting rather than the higher setting.
NOTE: The No Heat Temperature feature is not available on
the sensor cycles.
PUSH TO START
END OF CYCLE SIGNAL
Press to start a cycle or rotate to turn sound on/off.
2
3
Not all features and options are available on all models. Appearance may vary.
CYCLE GUIDE—TIMED DRY
Not all cycles and settings are available on all models.
TIMED DRY — Will run the dryer for the specified time on the control. Depending on model, temperature may be selected on cycle
knob or be a separate control.
Heavy or bulky items Heavy Duty* Any Completes drying if items are still damp.
Any load Timed Dry Any Dries items to a damp level for items that do not require an entire
drying cycle.
Select a drying temperature based on the fabrics in your load. If
you are unsure of the temperature to select for a load, select the
lower setting rather than the higher setting.
Rubber, plastic, heat-
sensitive fabrics
Timed Dry No Heat Use a no-heat setting for foam, rubber, plastic, or heat-sensitive
fabrics.
SPECIAL SETTING † :
Any load Wrinkle
Control †
No Heat After a cycle is complete, the load is periodically tumbled to
avoid wrinkles until you are ready to remove it.
Items to Dry: Cycle: Temperature: Cycle Details:
* NOTE: This clothes dryer’s Government energy certifications were based on the 60-minute/Timed Dry Cycle, and Maximum Drying Temperature
Setting. The as-shipped defaults of Normal Dry, Medium Temperature, and Sound Off were not used.
†This setting is added at the end of certain cycles to reduce wrinkling.
1 2
3
