6 cableado del circuito principal – Yaskawa CIMR-AU Manual del usuario
Página 116
Modelo de
variador
Terminal
Calibre recomendado
AWG, kcmil
Rango de cable
AWG, kcmil
Tamaño de
los
tornillos
Torque de ajuste
N·m (lb.in.)
2A0081
R/L1, S/L2, T/L3
2
3 a 2
M8
9.9 a 11.0
(87.6 a 97.4)
U/T1, V/T2, W/T3
2
3 a 2
⊖, ⊕1, ⊕2
–
3 a 2
B1, B2
–
6
M5
2.7 a 3.0
(23.9 a 26.6)
6
6 a 4
M6
5.4 a 6.0
(47.8 a 53.1)
2A0110
R/L1, S/L2, T/L3
1/0
3 a 1/0
M8
9 a 11
(79.7 a 97.4)
U/T1, V/T2, W/T3
1/0
3 a 1/0
⊖, ⊕1
–
2 a 1/0
B1, B2
–
6 a 1/0
6
6 a 4
2A0138
R/L1, S/L2, T/L3
2/0
1 a 2/0
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
2/0
1 a 2/0
⊖, ⊕1
–
1/0 a 3/0
B1, B2
–
4 a 2/0
4
4
M8
9 a 11
(79.7 a 97.4)
2A0169
R/L1, S/L2, T/L3
4/0
2/0 a 4/0
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
4/0
3/0 a 4/0
⊖, ⊕1
–
1 a 4/0
⊕3
–
1/0 a 4/0
4
4 a 2
2A0211
R/L1, S/L2, T/L3
1/0 × 2P
1/0 a 2/0
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
1/0 × 2P
1/0 a 2/0
⊖, ⊕1
–
1 a 4/0
⊕3
–
1/0 a 4/0
4
4 a 1/0
2A0250
R/L1, S/L2, T/L3
3/0 × 2P
3/0 a 300
M12
32 a 40
(283 a 354)
U/T1, V/T2, W/T3
3/0 × 2P
3/0 a 300
⊖, ⊕1
–
3/0 a 300
⊕3
–
2 a 300
M10
18 a 23
(159 a 204)
3
3 a 300
M12
32 a 40
(283 a 354)
2A0312
R/L1, S/L2, T/L3
4/0 × 2P
3/0 a 300
M12
32 a 40
(283 a 354)
U/T1, V/T2, W/T3
3/0 × 2P
3/0 a 300
⊖, ⊕1
–
3/0 a 300
⊕3
–
3/0 a 300
M10
18 a 23
(159 a 204)
2
2 a 300
M12
32 a 40
(283 a 354)
2A0360
R/L1, S/L2, T/L3
250 × 2P
4/0 a 600
M12
32 a 40
(283 a 354)
U/T1, V/T2, W/T3
4/0 × 2P
4/0 a 600
⊖, ⊕1
–
250 a 600
⊕3
–
3/0 a 600
M10
18 a 23
(159 a 204)
1
1 a 350
M12
32 a 40
(283 a 354)
2A0415
R/L1, S/L2, T/L3
350 × 2P
250 a 600
M12
32 a 40
(283 a 354)
U/T1, V/T2, W/T3
300 × 2P
300 a 600
⊖, ⊕1
–
300 a 600
⊕3
–
3/0 a 600
M10
18 a 23
(159 a 204)
1
1 a 350
M12
32 a 40
(283 a 354)
<1> Instale un GFCI al usar este calibre de cable, de acuerdo con IEC/EN 61800-5-1.
