6 cableado del circuito principal – Yaskawa CIMR-AU Manual del usuario
Página 121
Modelo de
variador
Terminal
Calibre recomendado
mm
2
(AWG, kcmil)
Rango de cables
mm
2
(AWG, kcmil)
Tamaño de
los tornillos
Torque de ajuste
N·m (lb.in.)
5A0041
R/L1, S/L2, T/L3
16
(6)
6.0 a 25
(10 a 3)
M8
9.0 a 11
(79.7 a 97.4)
U/T1, V/T2, W/T3
16
(6)
6.0 a 25
(10 a 3)
⊖, ⊕1
–
(6 a 1)
B1, B2
–
4.0 a 25
(12 a 3)
16
(6)
10 a 16
(6)
5A0052
R/L1, S/L2, T/L3
25
(4)
6.0 a 25
(10 a 3)
M8
9.0 a 11
(79.7 a 97.4)
U/T1, V/T2, W/T3
16
(6)
6.0 a 25
(10 a 3)
⊖, ⊕1
–
16 a 35
(6 a 1)
B1, B2
–
10 a 25
(8 a 3)
16
(6)
10 a 16
(6)
5A0062
R/L1, S/L2, T/L3
25
(4)
6.0 a 95
(10 a 4/0)
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
25
(4)
6.0 a 95
(10 a 4/0)
⊖, ⊕1
–
25 a 95
(4 a 4/0)
⊕3
–
16 a 95
(6 a 4/0)
25
(4)
25
(4)
5A0077
R/L1, S/L2, T/L3
25
(3)
6.0 a 95
(10 a 4/0)
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
25
(3)
6.0 a 95
(10 a 4/0)
⊖, ⊕1
–
25 a 95
(3 a 4/0)
⊕3
–
16 a 95
(6 a 4/0)
25
(4)
25
(4)
5A0099
R/L1, S/L2, T/L3
70
(1/0)
6.0 a 95
(10 a 4/0)
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
50
(1)
6.0 a 95
(10 a 4/0)
⊖, ⊕1
–
35 a 95
(2 a 4/0)
⊕3
–
25 a 95
(4 a 4/0)
25
(4)
25
(4)
5A0125
R/L1, S/L2, T/L3
70
(2/0)
35 a 150
(1 a 300)
M10
18 a 23
(159 a 204)
U/T1, V/T2, W/T3
70
(2/0)
35 a 150
(1 a 300)
⊖, ⊕1
–
70
(2/0 a 3/0)
⊕3
–
35 a 50
(1 a 1/0)
35
(3)
35 a 150
(3 a 300)
