Modelo de
variador
Figura
Dimensiones en mm (in) Diámetro en mm (in)
An Pr An1 An2 An3 An4 Pr1 Pr2 Pr3 Pr4 d5 d6 d7
4A0139F
7
111
(4.4)
109
(4.3)
56
(2.2)
15
(0.6)
30
(1.2)
66
(2.6)
119
(4.7)
109
(4.3)
53
(2.1)
41
(1.6)
51
(2.0)
36
(1.4)
61
(2.4)
4A0165F
111
(4.4)
109
(4.3)
56
(2.2)
15
(0.6)
30
(1.2)
66
(2.6)
119
(4.7)
109
(4.3)
53
(2.1)
41
(1.6)
51
(2.0)
36
(1.4)
61
(2.4)
4A0208A 8
175
(6.9)
130
(5.1)
91
(3.6)
84
(3.3)
25
(1.0)
–
137
(5.4)
51
(2.0)
41
(1.6)
–
51
(2.0)
61
(2.4)
36
(1.4)
4A0250A
9
191
(7.5)
130
(5.1)
104
(4.1)
30
(1.2)
28
(1.1)
71
(2.8)
157
(6.2)
71
(2.8)
51
(2.0)
–
51
(2.0)
61
(2.4)
43
(1.7)
4A0296A
191
(7.5)
130
(5.1)
104
(4.1)
30
(1.2)
28
(1.1)
71
(2.8)
157
(6.2)
71
(2.8)
51
(2.0)
–
51
(2.0)
61
(2.4)
43
(1.7)
4A0362A
191
(7.5)
130
(5.1)
104
(4.1)
30
(1.2)
28
(1.1)
71
(2.8)
157
(6.2)
71
(2.8)
51
(2.0)
–
51
(2.0)
61
(2.4)
43
(1.7)
Clase de 600 V
5A0003F
1
43
(1.7)
38
(1.5)
38
(1.5)
– – –
41
(1.6)
71
(2.8)
79
(3.1)
–
23
(0.9)
36
(1.4)
–
5A0004F
43
(1.7)
38
(1.5)
38
(1.5)
– – –
41
(1.6)
71
(2.8)
79
(3.1)
–
23
(0.9)
36
(1.4)
–
5A0006F
43
(1.7)
56
(2.2)
38
(1.5)
– – –
41
(1.6)
71
(2.8)
79
(3.1)
–
23
(0.9)
36
(1.4)
–
5A0009F
43
(1.7)
56
(2.2)
38
(1.5)
– – –
41
(1.6)
71
(2.8)
79
(3.1)
–
23
(0.9)
36
(1.4)
–
5A0011F
43
(1.7)
56
(2.2)
38
(1.5)
– – –
41
(1.6)
71
(2.8)
79
(3.1)
–
23
(0.9)
36
(1.4)
–
5A0017F
2
25
(1.0)
76
(3.0)
56
(2.2)
– – –
48
(1.9)
84
(3.3)
53
(2.1)
–
36
(1.4)
23
(0.9)
43
(1.7)
5A0022F
25
(1.0)
76
(3.0)
56
(2.2)
– – –
48
(1.9)
84
(3.3)
53
(2.1)
–
36
(1.4)
23
(0.9)
43
(1.7)
5A0027F
28
(1.1)
79
(3.1)
64
(2.5)
– – –
51
(2.0)
86
(3.4)
56
(2.2)
–
36
(1.4)
23
(0.9)
43
(1.7)
5A0032F
28
(1.1)
79
(3.1)
64
(2.5)
– – –
51
(2.0)
86
(3.4)
56
(2.2)
–
36
(1.4)
23
(0.9)
43
(1.7)
5A0041F
3
89
(3.5)
99
(3.9)
41
(1.6)
23
(0.9)
– –
99
(3.9)
43
(1.7)
25
(1.0)
–
61
(2.4)
28
(1.1)
51
(2.0)
5A0052F
89
(3.5)
99
(3.9)
41
(1.6)
23
(0.9)
– –
99
(3.9)
43
(1.7)
25
(1.0)
–
61
(2.4)
28
(1.1)
51
(2.0)
5A0062F
7
111
(4.4)
109
(4.3)
56
(2.2)
15
(0.6)
30
(1.2)
66
(2.6)
119
(4.7)
109
(4.3)
53
(2.1)
41
(1.6)
51
(2.0)
36
(1.4)
61
(2.4)
5A0077F
111
(4.4)
109
(4.3)
56
(2.2)
15
(0.6)
30
(1.2)
66
(2.6)
119
(4.7)
109
(4.3)
53
(2.1)
41
(1.6)
51
(2.0)
36
(1.4)
61
(2.4)
5A0099F
111
(4.4)
109
(4.3)
56
(2.2)
15
(0.6)
30
(1.2)
66
(2.6)
119
(4.7)
109
(4.3)
53
(2.1)
41
(1.6)
51
(2.0)
36
(1.4)
61
(2.4)
5A0125A
8
175
(6.9)
130
(5.1)
91
(3.6)
84
(3.3)
25
(1.0)
–
137
(5.4)
51
(2.0)
41
(1.6)
–
51
(2.0)
61
(2.4)
36
(1.4)
5A0145A
175
(6.9)
130
(5.1)
91
(3.6)
84
(3.3)
25
(1.0)
–
137
(5.4)
51
(2.0)
41
(1.6)
–
51
(2.0)
61
(2.4)
36
(1.4)
5A0192A
9
191
(7.5)
130
(5.1)
104
(4.1)
30
(1.2)
28
(1.1)
71
(2.8)
157
(6.2)
71
(2.8)
51
(2.0)
–
51
(2.0)
61
(2.4)
43
(1.7)
5A0242A
191
(7.5)
130
(5.1)
104
(4.1)
30
(1.2)
28
(1.1)
71
(2.8)
157
(6.2)
71
(2.8)
51
(2.0)
–
51
(2.0)
61
(2.4)
43
(1.7)
Nota: Quitar la cubierta protectora superior o la abrazadera inferior de conductos portacables de un variador con gabinete IP20/NEMA tipo
1 anula la protección de NEMA tipo 1 y mantiene el conformidad con IP20.
2.2 Instalación mecánica
